Food Processing LED High Bay Light

Features:

  • IP69K IK10
  • High Output LED'sup to 140m/W standard,160lm/W options.
  • CRI>70 standard (80/90 option)
  • Isolated Driver with Overheat Protection, High PF>0.9, low THD, Flicker-free.
  • Environmentally friendly, no mercury, No UV, No IR.
  • 60°/90/120°beam angle.
  • Energy Efficiency Grade: C
  • Quick Start instant 100% luminous flux.
  • 5-Year Warranty
  • Certificate: CE, RoHS
  • Body: Aluminium alloy
  • Stainless steel screws
  • Options: 1-10V, DALI Dimming

Description

The Food Processing LED High Bay Light is specifically designed for use in challenging environments such as food and beverage, garden centers, and industrial facilities. It meets the requirements of NSF for food processing applications by not having any glass or exposed screws. The IP69K waterproof structure makes it ideal for areas that require hose-down cleaning. The Clean High Bay Series fixtures bring the benefits of LED lighting to high mounting heights in food processing facilities, which were traditionally limited to HID lighting.

With no screws on the front, the smooth back of the high bay ensures minimal dust accumulation. This makes it easy to clean without the risk of any screws or small parts falling off when using a high-pressure water gun.

The surface coating of the high bay has been tested and meets the standards of REACH, ROHS, and HALOGEN, as confirmed by SGS. It is equipped with either a Meanwell HBG driver or a MOSO Isolated Driver, ensuring a high power factor (>0.96), low total harmonic distortion (THD), and flicker-free operation. Additionally, the high bay is environmentally friendly with no mercury, UV, or IR emissions.

The TUBU's Food Processing LED High Bay Light structure is constructed using aluminum alloy, ensuring durability and longevity.

Tech Specs

Product Code

TBF10-100W

TBF10-120W

TBF10-150W

Power

100W

120W

150W

Input Voltage

90-305VAC

Input Current

0.47A

0.57A

0.66A

PF

>0.98@220VAC

Dimming Option

0-10V/Dail Dimming

CCT

3000K/4000K/5000K/6000K

Ra>80

Luminous Flux

14000Lm±5%/15000Lm±5%

16800Lm±5%/18000Lm±5%

21000Lm±5%/225000Lm±5%

Ra>80

Efficiency

140Lm/W±5%/150Lm±5%

LED Brand

3030

Beam Angle

60°/90°/120°

Operation Temp

-40℃~+45℃

Storage Temp

-40℃~+85℃

Life Span

Ta 45℃ L70>54000Hours

IP Class

IP69K

IK Class

IK10

Certificate

CE, RoHS

Lamp Body Color

Gray (RAL9007)

Product Size (mm)

400*400*197

Net weight (kg) ±0.3

5.8

Package Size (mm)

470*470*210

Gross weight (kg) ±0.3

6.8

Installation mode

Hook/Pendant Mount

Food Special
LED High Bay Lightight

High Output LED at 140m/W standard, 160lm/W options. CRI>70, standard (80/90 option), Energy Efficiency Grade: C

Over-Temperature
Protection And Flicker-Free

Equipped with 4KV/6KV power surge over-temperature protection and high PF>0.9, low THD, high lumen output flicker-free isolated driver.

Secure Installation, Rugged Design

Features durable screw safety chain mounting holes for secure installation. Use a food-grade powder coat finish and rugged die-cast aluminum housing. In addition, it has a self-cleaning appearance.

Perfect Angles, Seamless Dimming

The beam angle is 60°/90°/120° optional, compatible with 1-10V and DALI dimming system, can flexibly control the brightness of the light, and achieve different light distributions.

IP69K Protection Level

It has an IP69K waterproof construction, making it ideal for areas that require washdown. It is more suitable for the food processing industry, without fear of high-pressure water guns.

Installation Mode

Food Processing LED High Bay Light Installation Mode

Applications

food processing lighting
Food Processing Plant Lighting
Processing plant lighting
