LED tri proof light

What is the LED tri proof light?

Waterproof, dustproof, and anti-corrosion refers to LED tri proof light. Many people may not know much about LED tri proof light, because in daily life, most of the lamps we come into contact with are functional or decorative lamps. Therefore, our standard for judging whether a lamp is excellent or not is also most of the lighting quality evaluation or the aesthetics of the lamp. LED tri proof light workplaces have very strict requirements for lamps. As LED tri proof light is widely used in steel, petroleum and petrochemical, tunnels and various factories, workshops, stations, and large facilities, etc., safety and stability are the core parts of LED tri proof light. With the development of the lighting industry today, many technologies have become mature. Therefore, new requirements have been put forward in terms of light efficiency, appearance, heat dissipation, installation methods, and manufacturing processes.

Compared with the traditional tri proof light, the material has also made great progress. The lamp body and bracket adopt steel plate. The port of the lamp and the waterproof connector are made of PC plastic, which has better protection performance in harsh environments.

LED tri proof light, protection ability is the top priority

In rainy areas, the indoor and outdoor humidity is disturbing, and the damage of lamps and lanterns will affect the operation activities. Especially underground spaces such as factory workshops and subway pipelines have special requirements for waterproof, dustproof, and corrosion-resistant appliances, which puts forward higher requirements on lighting fixtures. Regardless of the internal and external environments, a safe lighting environment is the top priority weight. TUBU’S LED Tri-proof light fixture the body and lampshade are made of aluminum and polycarbonate to ensure its rugged performance. The uniquely designed sealing ring and stainless steel buckle provide IP65 IP67 IP69K protection against water and dust ingress, extremely humid, and dusty. Under the same conditions, it can also provide the best lighting effect. Excellent light distribution can save energy and reduce power consumption while ensuring the necessary lighting in industrial sites. Installation and maintenance can be carried out without complicated tools, saving installation time and labor costs.

LED tri proof light connection:

Each lamp of the traditional tri-proof lamp is an independent individual and cannot be used in series. TUBU’s LED tri proof light can be installed in series. The quick connector can simple opening is convenient for serial connection of lamps.

IP Grade of LED tri-proof light

What does LED tri-proof light protection standard IP69K mean?

The code for the enclosure protection class is usually composed of the characteristic letter IP and two characteristic numbers. The first figure refers to the following: prevent the human body from touching or approaching the live parts inside the enclosure and touching the moving parts (except for smooth rotation and the like) to prevent the protection of solid foreign objects into the enclosure; the second figure refers to preventing water from entering the enclosure The interior achieves a degree of protection against harmful levels.

The first marked number definition:

IP0X: No protection, No special protection against people or things outside.

IP1X:Prevent the penetration of solid objects larger than 50mm: Prevent the human body (such as palm) from accidentally touching the parts inside the lamp. Prevent intrusion of foreign objects of larger size (diameter greater than 50mm).

IP2X:Prevent intrusion of solid objects larger than 12mm: Prevent human fingers from coming into contact with parts inside the fixture to prevent intrusion of foreign objects of medium size (12mm in diameter).

IP3X:Prevent intrusion of solid objects larger than 2.5 mm: Prevent tools, wires, or similar small foreign objects with a diameter or thickness greater than 2.5 mm from intruding into contact with parts inside the fixture.

IP4X:To prevent the invasion of solid objects greater than 1.0mm: to prevent the diameter or thickness of more than 1.0mm tools, wires or similar details of small foreign objects invade and touch the interior parts of the lamp.

IP5X:Dust-proof:It completely prevents the intrusion of foreign objects. Although it cannot completely prevent dust from entering, the amount of intruded dust does not affect the normal operation of the lamp.

IP6X Dust-proof: It completely prevents the intrusion of foreign objects and completely prevents dust from entering.

The second tag number definition:

IPX0:No protection: No protection.

IPX1:Prevent drip intrusion: Drops of water (such as condensate) that are dropped vertically will not have a detrimental effect on the luminaire.

IPX2:It can still prevent the intrusion of the drip when tilted at 15 degrees: When the light is tilted to 15 degrees from the vertical, the drip will not cause harmful effects on the light.

IPX3:To prevent the intrusion of sprayed water: prevent rain, or prevent water sprayed into the fixture with a vertical angle less than 60 degrees to cause damage.

IPX4:To prevent the intrusion of splashing water: to prevent splashing water in all directions into the lamp to cause damage.

IPX5:To prevent the intrusion of water: prevent water from the nozzles from all directions to enter the lamp to cause damage.

IPX6:To prevent the intrusion of large waves: lamps installed on the deck to prevent damage caused by the invasion of large waves.

IPX7: To prevent water intrusion when flooding: The lamp is immersed in water for a certain time or water pressure below a certain standard to ensure that it does not cause damage due to water.

IPX8:Prevent intrusion of water when sinking: The lamp sinks indefinitely under specified water pressure conditions to ensure that it is not damaged due to water ingress.

IP69/69K: Capable of withstanding the thermal steam wash test defined in EN 60529 and DIN 40050-9. This provides protection against water pressures of 100 bar (1450 psi) and temperature of 80oC. The pressure is applied directly to the sensor at progressive angles of 30 degrees (0, 30, 60, and 90 degrees) for 30 seconds at each angle for a total of 120 seconds (2 minutes) to prevent water ingress.

What kind of corrosion can LED tri-proof light resist?

The corrosion resistance of LED tri-proof light depends on the material used, and the corrosion resistance of different materials will vary. The commonly used materials for LED tri-proof light are PC, ABS, PMMA, GLASS, PET. Let us introduce some of the main differences between PC and PMMA LED tri-proof light.
1. Physical properties: PC has better toughness and impact strength than PMMA, PMMA is a brittle material.
2. Temperature resistance: PC has better temperature resistance than PMMA. PC’s TG reaches 120°, while PMMA is only 85°.
3. Wear resistance: PC has better wear resistance than PMMA, but the surface scratch resistance is far inferior to PMMA, so the scratch-resistant high-gloss ABS material is alloyed with PMMA.
4. Fire resistance: PC has better fire resistance than PMMA, that is, it has better fire resistance. Ordinary PC can reach fire resistance V2, V0,5VA,5VB
5. Light transmittance: PMMA has much better light transmittance than PC. PMMA has a light transmittance of 92~93%, which is the best among transparent materials. Therefore, multiple light guide plates and medical equipment are often used, and PC is only 86~89 %.
6. Weather resistance: PMMA has excellent weather resistance. It is often used as outdoor products, and PC is used as outdoor products.
Add UV agent and antioxidant.

If you want to know the specific chemical resistance of Plastic, please check the file Plastic Resistance.
