LED Tri-proof Light L9-360°

Features:

  • IP40
  • PC IK08
  • System efficiency up to 100Lm/W & 120Lm/W
  • Environmentally friendly, no mercury, no UV, no IR
  • High CRI>80
  • Wide beam angle 360°
  • Energy efficiency grade: C
  • Quick start instant 100% Iuminous flux
  • Certificate: CE, RoHs Certified
  • 5 years warranty on complete fixture (LED’s, driver & housing)
  • Surface Mount or Suspension Mount

Description

LED tri-proof light L9-360° is a high-performance, cost-effective lighting products, IP40 dustproof and waterproof, IK08 impact resistance, can withstand dust, water, impact and other harsh environments.L9-360° using high-quality LED lamp beads and drivers, with ultra-high luminous efficacy, ultra-long life, ultra-protection, etc., the color rendering index (CRI) of >80, showing the true color of the object for the LED tri-proof light L9-360° is suitable for indoor and outdoor lighting. It supports surface mounting or pendant mounting, and the LED Tri-Light L9-360° is CE and RoHS certified for quality assurance.

Tech Specs

Product Code

TBL92F-20W

TBL94F-30W

TBL94F-40W

Power

20W

30W

40W

Input Voltage

200-240VAC(50/60Hz)

Input Current

0.1A@220VAC

0.21A@220VAC

0.25A@220VAC

PF

0.90@220VAC

Dimming Option

0-10V/ DALI

CCT

2700K / 3000K / 4000K / 5000K / 5700K / 6000K /6500K

Luminous Flux

2000Lm

2400Lm

3000Lm

3600Lm

4000Lm

4800Lm

Efficiency

100Lm/W±5%

120Lm/W±5%

LED Brand

Lumileds/Hongli 2835

Beam Angle

360°C

Operation Temp

-20C~+40°C

Storage Temp

-20C~+60°C

Life Span

Ta 40C L70>54000hours

IP Class

IP40

IK Class

PC IK08

Certificate

CE, RoHs

Lamp Body Color

Milky PC

Product Size (mm)

Ø75*552

Ø75*1152

Ø75*1452

Packing Size (mm)

730*260*260

1330*260*180

1630*260*180

Quantity/carton

9PCS

6PCS

6PCS

Gross weight (kg) ±0.3

13

12

14

Installation mode

Surface Mount/Suspension Mount

Powerful performance and long-lasting durability

System efficiency up to 100Lm/W and 120Lm/W, energy saving and environmental protection. IP40 dust and water resistant, IK08 impact resistant, suitable for harsh environments. Up to 5 years of service life, eliminating the need for frequent replacement (lamp bead, driver and housing warranty).

Safe and reliable, is trustworthy

No mercury, no UV, no infrared radiation, environmentally friendly and safe. Fast startup, 100% brightness immediately. CE and RoHS certified for quality assurance.

Omni-directional illumination, no dead angle

Wide-viewing angle light distribution design, covering a larger area to meet a variety of lighting needs. Color Rendering Index (CRI) >80, showing the true color of the object.


Flexible to meet various needs

Support surface mounting or hanging, easily adapt to different installation environments. LED tri-proof light L9-360° is your best choice for indoor and outdoor lighting!

Application

Hospital, Office, Restaurant, Warehouse, Shopping centre, Coffee.
